Ace Belt Driven Centrifugal Pump 20-Spline 1.25″ Suction x 1″ Discharge @ 65 GPM
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | Farmer Bob's Parts |
| Model | Not Listed |
| MPN | PTOC-1000-20SP |
| Country/Region Of Manufacture | United States |
| Type | Centrifugal |
| Series | PTOC Series |
| Material | Cast Iron |
| Color | Green |
| Size | PTOC Series |
| Style | Belt Driven |
The original belt drive standard since 1964. Time tested and field proven design. Widespread parts and service availability. Most Economical belt drive. 20 spline 1-3/4" (44.5 MM) split bore shaft with locking collar for larger 1000 RPM PTO Models. Port sizes: Inlet 1-1/4" NPT, Outlet 1" NPT. Max Pressure: 80 PSI Max Flow: 65 GPM Weight: 45 lbs Our eBay Store About Us Contact Us Add to Favorite Sellers Ace Belt Driven Centrifugal Pump 20-Spline 1.25" Suction x 1" Discharge @ 65 GPM 899.95 PTOC-1000-20SP Suction 1-1/4" Female Pipe Thread Discharge 1" Female Pipe Thread Chemical Resistant Valox Impeller Standard Viton Carbon/Ceramic Mechanical Seal Spring loaded idler absorbs shock of PTO engagement New BAC-15-PIN feature ensures proper alignment Cast iron centrifugal with for direct mount on 20 spline, 1-3/4", 1000 RPM PTO Shaft Maximum Gallons Per Minute - 65 GPM Maximum PSI - 80 PSI Do Not Run Dry - Seal damage will result from running dry. Impeller damage may also occur if run dry for an extended period. Do Not Run With Flow Shutoff For Extended Periods - Running the pump with no flow for extended periods of time will result in excessive heat and pump failure. A continuous bypass is recommended for low flow applications
