MKS 1579A/1579A00132LR1BV713 300 slm He Digital Mass Flow Controller (MFC)
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| MPN | 1579A00132LR1BV713 |
| Brand | MKS Instruments |
| Maximum Flow Rate | 300000 SCCM (300 SLM) |
| Model | 1579A |
MKS 1579A/1579A00132LR1BV713 300 slm He Digital Mass Flow Controller (MFC) Comes with what you see in the pictures. If you don't see it, you probably won't get it. Specifications are from MKS and may vary slightly due to upgrades, options, or revisions this unit may or may not have. These units were removed from service in working condition but we have no way to test them and are selling them as-is, untested, for parts or not working. The Unit's Serial Number Tag Reads: Model Number: 1579A00132LR1BV713 / FKM Serial Number: Multiple Available Gas Type: He Flow Range: 300 slm CE Marked: Yes Breakdown by Part Number: Type: 1579A Mass-Flo Controller Gas to be Calibrated For: He Full Scale Range of Calibrated Gas: 300 slm Fittings (Compatible With): Swagelok 8 VCR Male Valve: Normally Closed Connector: Analog 15-pin Type D Seal Materials: Viton Firmware: 713 Description: The MKS Type 1579 is a digital mass flow controller of the latest generation developed for a multitude of applications in research and industry. The 1579 is based on proven MKS technology and offers a fast controller settling time as well as high accuracy in the entire control range. For example, this makes it possible to integrate the 1579 into fast cycle processes in which the idle time for the stabilization of the process conditions has to be minimal and reproducible. Due to its compact design, the 1579 allows space-saving designs of gas supply systems. The electrical connection is provided via Sub-D-connectors for both analog and Profibus variants in conformance with all CE regulations. Whereas in R&D mass flow controllers are mainly used in conjunction with power supply and readout units developed by MKS especially for this purpose, OEMs in industry focus increasingly on digital, bus-compatible components. Features & Benefits: Full Scale Flow Ranges from 50 slm to 300 slm (this unit is 300 slm) Multiple Supply Voltages 24 VDC and ±15 VDC Controller Settling Time of less than 1 second Available with analog and Profibus DP interface (this unit is an Analog Type) Storage of up to 15 Gas Tables (Multigas/Multirange) Plug-compatible with earlier MKS MFCs Compact design Analog Interface Version comes with a diagnostics port CE Mark compliant Specifications: Flow Range Full Scale (N2 in slm): 300 slm (this unit is He) Max. Inlet Pressure: 100 psig Normal Operating Pressure Differential: 40 to 49 psid (with atmospheric pressure at the MFC outlet) Control Range: 2 to 100% of F.S. Accuracy: ±1% of F.S. (including non-linearity, hysteresis, and non-repeatability; referenced to 760 mmHg and 0°C) Repeatability: ±0.2% of F.S. Resolution: 16 Bit Temperature Coefficients: Zero: < 0.05% of F.S./°C Span: < 0.10% of F.S./°C Warm-Up Time: < 30 min Controller Settling Time: < 1 s typical Pressure Coefficient: ±0.02% of Rdg/psi Normal Operating Temperature Range: 15°C to 40°C (59°F to 104°F) Input Voltage Required: 20.5 to 30 VDC Max. Current: 300 mA Set Point Command Signal: 0 to 5 VDC from 10 kOhm Connector Type: 15-pin Type "D" male Wetted Materials: Standard: 316L S.S.T., Nickel, Viton Leak Integrity: External: < 1 x 10-9 scc/sec He Through Closed Valve: < 0.1% of F.S. Fittings (Compatible With): Swagelok VCR 8 Male Electromagnetic Compatibility: Fully CE Compliant to EMC Directive 89/336/EEC when used with an overall metal braided shielded cable, properly grounded at both ends. For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $10.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I will need to know the following information (filled out on a form that I will send you) for International Customers or Packages/Freight being Forwarded internationally. International customers may also be subject to a freight forwarder form if applicable.: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? 06/26/17
